Maritime cranesProductsPort equipmentLHM 180

Whether it is containers, bulk or general cargoes - with a maximum outreach of 35 metres and a capacity of 64 tonnes the LHM 180 is the right handling solution for feeder and handysize ships. The LHM 180 impresses with its mobility and flexibility, particularly in inland ports.

metricimperial

  • Lifting capacity (max.) - 64 t

  • Jib length - 35 m

  • Total weight - 165 t

  • Hoisting/lowering max. - 90 m/min

product image 0
Stage V / Tier 5 final engine
The Liebherr mobile harbour crane is equipped with the latest generation of diesel engines for the exhaust emissions standards of EU stage V or EPA Tier 5 final.
Driver's cab
Noise protection, windshield wiper, air conditioning. The ergonomic and comfortable features of the cab increase the concentration and reduce the fatigue of the crane operator – for consistently high productivity and a high level of safety.
Safety devices
The safety of people, the infrastructure and the environment takes top priority. Our mobile harbour crane has a number of precautionary measures for increased safety in your port.
Four-rope grab control
The synchronisation of the winches is monitored and optimised by the four-rope grab control.
Hydrostatic drive
Closed hydraulic loops are used for all main functions such as lifting, turning and luffing. The crane operator benefits from extremely precise control, the service personnel benefit from a minimum number of components and the operating company benefits from reduced fuel consumption.
Pull cylinder
The pull cylinder over the boom offers many advantages: no collision with swinging load, no buckling of the cylinder and full protection of the piston rod in park position.
Lifting capacity (max.)
64 t
Max. load bulk
42 t
Radius min.
9.00 m
Jib length
35 m
Total weight
165 t
Container rows max.
11
Max. ship width bulk
38 m
Max. ship width scrap
29 m
Material handling capacity bulk
800 t/h
Engine power
400 kW
Hoisting/lowering max.
90 m/min
Slewing max.
1.60 rpm
Luffing max.
83 m/min
Travel speed max.
5.40 km/h
Mobility
rubber tyred
Fields of application
Bulk handling / Container handling / General cargo operation / Heavy lift / Scrap handling
Lifting height max.
42 m

LHM 180

Liebherr LHM mobile harbour cranes

Liebherr Electronics

Maritime Customer Service

Intelligent grabber
The innovative system detects the properties of the material and fills the grabber optimally for each work cycle.
Pendulum-free load
Cycoptronic anticipates the path of the load and balances out any pendulum movements even before they develop.
Soft Touch Down
The system detects how much space is available between the container and destination and optimises the braking distance.
Synchronised lifting
One system, two cranes and only one crane operator: Sycratronic brings several cranes together as one functioning unit.
Vertical Line Finder
The avoidance of sideways pull and precise vertical lifting of the load increase the service life of the crane.
Radio remote control
The radio remote control combines user-friendliness and functionality. All crane movements are easy to control, also from outside the cab.
